4 Way DVI 4K Splitter

FEATURES:

• 1X DVI-D input and 2/4/8/16X DVI-D output
• Support dual Link DVI-D signal transmission, resolution up to 3840X2160@30Hz
• Support resolution 640X480@60Hz to 3840X2160@30Hz, compatible with the HDMI 1080P standard
• Support for long distance signal transmission
• Installs in minutes, No loss of quality
• Supports wide range voltage DC input (DC5V~12V)

SPECIFICATIONS:

• DVI interface type ........................................ Dual link DVI-D
• Single link input/output resolution ....................up to 1920x1080@60Hz
• Dual link input/output resolution ............................up to 3840x2160@30Hz
• Support video color format ........................24bit/deep color 30bit,36bit
• Max signal bandwidth.................................340MHz
• Max baud rate...............................3.4Gbps Serial Link
• Input/Output TMDS signal .........................0.5~1.5Volts p-p(TTL)
• Input/Output DDC signal ............................ 5Volts p-p (TTL)
• DVI input cable distance................≤10m AWM 20276 DVI standard cable
• DVI output cable distance.................≤10m AWM 20276 DVI standard cable
• Max working current ...........................0.8A/5V (DVISP002M1)
• Max working current ..............................1.2A/5V (DVISP004M1)
• Max working current ............................1.5A/12V (DVISP008M1)
• Max working current ............................2.5A/12V (DVISP016M1)
• Power adapter .......AC 100V～240V 50HZ/60Hz, DC5V/2A(DVISP002M1/DVISP004M1)
• Power adapter .......AC 100V～240V 50HZ/60Hz, DC12V/3A(DVISP008M1/DVISP016M1)
• Operating Temperature range ............................ -5 to +45℃
• Storage Temperature range........................... -15 to +55℃
• Operating Humidity range .....................10 to 90%RH (No Condensation)
• Storage Humidity range......................5 to 95%RH (No Condensation)
• Case Dimension (L x W x H) ................... 179x66x28mm (DVISP002M1)
• Case Dimension (L x W x H) ...................277x136x27mm (DVISP004M1)
• Case Dimension (L x W x H) ...................482x180x44mm (DVISP008M1)
• Case Dimension (L x W x H) ...................482x180x66mm (DVISP016M1)
• Weight ....................................370g (DVISP002M1)
• Weight ....................................800g (DVISP004M1)
• Weight ...................................1.5kg (DVISP008M1)
• Weight ...................................1.8kg (DVISP016M1)
