1M QSFP+ ( 40G ) To 4x SFP+ ( 10G ) Splitter Cable

1M QSFP+ To 4x SFP+ Cable

Introduction:

The QSFP+ to 4x SFP+ copper DAC cable is a 40GBase QSFP+ passive cable. One side is with a QSFP+ connector, and the otrher side has 4 x SFP+ plugs. It’s used to connect the QSFP+ port on a 40Gb/s switch or host to 4 upstream 10Gb/s switches or hosts.

Features:

•  QSFP (40G) to 4x SFP+ (10G) Splitter Cable – 1M
•  Connector A: (1) QSFP 40.0 Gb/s Rated Connector (SFF-8436 Compliant)
•  Connector B: (4) SFP+ 10.0 Gb/s Rated Connectors (SFF-8431 Compliant)
•  Economically Links up a QSFP port with an Upstream 10GbE-SFP+ Switch
•  30AWG Pure Copper
•  Protocol agnostic support of 40GbE, QDR InfiniBand, SAS & Fibre Channel
•  Up to 10.3125 Gb/s transfer rate per SFP+ channel (40 Gb/s aggregate)
•  Robust Zinc die-cast SFP+ & QSFP connectors with pull-to-release latching
•  Bridge the gap between your 10G and 40G capable switches/host adapters
•  Low cross-talk and pair-to-pair skew maintains signal integrity

•  Supports all current 10-Gigabit Ethernet and 40-Gigabit Ethernet standards
•  Designated form factor and electrical compliance for QDR InfiniBand
•  The perfect direct attached storage splitter cable for Fibre Channel & SAS
•  Enjoy a reduced power budget and lower port cost compared to optical
•  Fully RoHS compliant for environmental protection
