CAT6A Right Angle Field Terminator

Introduction

This Right Angle CAT6A Tool-Free Field Terminator is designed for quick, reliable, and efficient terminations in high-speed networking environments without the need for specialized tools. Its right-angle design allows for space-saving installation in tight spaces such as data centers, wall outlets, and patch panels, ensuring neat cable management. Supporting 10 Gigabit Ethernet and meeting CAT6A performance standards, this terminator delivers superior signal integrity, reduced crosstalk, and dependable performance for high-bandwidth applications. The tool-free mechanism ensures fast and secure connections, making it an ideal choice for professional installers and IT technicians.

The smart design of this field terminator allows the users to make right angle or normal straight connectors.

Specifications

• Category Standard: CAT6A
• Connector Type: Tool-free field terminator, with detachable right angle module to allow users to make right angle or straight plugs
• Performance: Supports up to 10Gbps Ethernet, 500 MHz bandwidth
• Compatibility: Works with 23–26 AWG solid and stranded UTP/STP cables
• Termination Method: Tool-free IDC termination with easy latch mechanism
• Wire Scheme: Supports both T568A and T568B wiring standards
• Shielding: Available in shielded and unshielded versions (depending on model)
• Contact Material: Phosphor bronze with gold plating for superior conductivity
• Housing Material: Durable zinc alloy (shielded type) or high-impact ABS plastic (UTP type)
• Operating Temperature: -10°C to +60°C
• Compliance: ANSI/TIA-568.2-D, ISO/IEC 11801, IEC 60603-7-51
• Applications: Data centres, structured cabling, wall outlets, patch panels, industrial and commercial networks
