PCI 8 Port Low Profile Serail Port Card
$324.50
Tax included
PCI 8 Port Low Profile Serail Port Card
n
nn
nnn
nn
n
n
nn
nn n
nSUNIX SER5066A, Universal PCI serial communication board, allows users to add or expand eight RS-232 ports on PC-based system. The card is compatible with both 64 / 32-bit PCI architecture supporting 3.3 and 5V Bus, allowing it to be installed in virtually any PC-based systems. SUNIX SER5066A card has 128-bytes onboard FIFO buffer and compatible with 16C950 UART specification. It is designed with SUNIX UART controller, SUN1999 and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.
nn
n
nn
nnn
nn
nn
nn
nnnn
n
n| nn | n|
| Product Description | n8-port RS-232 Universal PCI Serial Board | n
| nn | n|
| Interface | nRS-232 | n
| Controller | nSUNIX SUN1999 (16C950 UART Compatible) | n
| Bus | nUniversal PCI 64/32bit 3.3V/5V PCI Ver 3.0, 2.3, 2.2, 2.1 | n
| No. of Port | n8-port | n
| IRQ & IO | nAssigned by System | n
| FIFO | n128 byte (Hardware) | n
| Signal | nTxD, RxD, RTS, CTS, DTR, DSR, DCD, GND | n
| Baud rate | n50 bps to 115.2 Kbps | n
| Data bit | n5,6,7,8 | n
| Stop bit | n1,1.5,2 | n
| Parity | nNone, Even, Odd, Space, Mark | n
| Flow Control | nNone, Xon/Xoff, RTS/CTS | n
| Protection | n±2KV ESD protection for each signal Human Body Model (HBM) | n
| PCB connector | nDB62 Female | n
| nn | n|
| Windows Client | nXP / Vista / 7 / 8.x / 10 (X86/X64) | n
| Windows Server | n2003 / 2008 / 2012 / 2016 (X64) | n
| Windows Embedded | nWindows XP Embedded / POSReady 2009 / POSReady / Embedded System 2009 | n
| Linux | nLinux 2.x / 3.x / 4.x | n
| DOS | nDOS | n
| FreeBSD | nFreeBSD 5.3~5.5 / 6.0~6.4 | n
| QNX | nQNX 6.3.2/6.4.0 | n
| * IBM OS/2 | nWARP 3/WARP 4 | n
| * SCO UnixWare | nUnixWare 7.1.3/7.1.4/ Open Server 5.0.7/6.0 | n
| * Sun Microsystems | nSolaris 10 | n
| Note : “ * ” Supported by special inquiry. | n|
| nn | n|
| Hardware | nEN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, BSMI: CNS13438, RoHS | n
| Software | nMicrosoft WHQL Windows • Windows Client: XP / Vista / 7 / 8.x / 10 (X86/X64) • Windows Server: 2003 / 2008 / 2012 / 2016 (X64) | n
| nn | n|
| Operation Temperature | n0 to 60°C (32 to 140°F) | n
| Operation Humidity | n5 to 95% RH | n
| Storage Temperature | n-20 to 85°C (-4 to 185°F) | n
| nn | n|
| PCB Dimension | n125 x 100 mm | n
| Bracket | nStandard 121 mm | n
| Bracket Space | n1 | n
n
nn
nn
nnn
nn
nn
nnn
nn
nn
n
nDB62 to 8-port DB9 Male Connection Cable
nn
n- n
- 40 cm n
- Part No.: 1WDB-62M04009D8000 n
- 1 pcs. nn
CTR5066AL
100 Items
New
