SUNIX SER4066RM PCI 8 Port RS232 Serial Card
$462.50
Tax included
SUNIX SER4066RM PCI 8 Port RS232 Serial Card
SUNIX SER4066RM, Universal PCI serial communication board, allows users to add or expand four RS-232 ports on PC-based system. The card is compatible with both 64 / 32-bit PCI architecture supporting 3.3 and 5V Bus, allowing it to be installed in virtually any PC-based systems. SUNIX SER4066RM card has 32-bytes onboard FIFO buffer and compatible with 16C650 UART specification. SUNIX GoldenIO card series is designed with SUNIX UART controller, Matrix and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.
Features
- Expands 8 independent RS-232 serial ports with communication speeds up to 115.2Kbps.
- High speed Matrix 16C750 compatible UART controller on-board.
- Compliance with PCI 33MHz Ver 2.2 & 2.1 specification.
- Supports both 64-bit 32-bit PCI bus slot and 3.3V & 5V power.
- On-chip hardware auto flow control to guarantee no data loss.
- Built-in ±2KV ESD protection for all serial signals.
- Plug-n-Play, I/O address and IRQ assigned by BIOS.
- Certified by CE, FCC, RoHS, and Microsoft WQHL approval.
- Support Microsoft Windows, Linux, and DOS.
| Product Description | 8 ports RS-232 Serial PCI Board |
| Interface | RS-232 |
| Controller | Matrix (16C750 UART Compatible) |
| Bus Interface | Universal PCI 64/32bit 3.3V/5V PCI Ver 2.2/2.1 |
| No. of Port | 8-port |
| IRQ & IO | Assigned by System |
| FIFO | 32 byte (Hardware) |
| Signal | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| Baud rate | 50 bps to 115.2 Kbps |
| Data bit | 5,6,7,8 |
| Stop bit | 1,1.5,2 |
| Parity | None, Even, Odd, Space, Mark |
| Flow Control | RTS/CTS (Hardware) , XON/XOFF(Software) |
| Protection | ±2KV ESD protection for each signal Human Body Model (HBM) |
| PCB connector | DB62 Female |
| Microsoft | 3.1/95/98/NT/ME/2000/XP/2003/Vista (32/64 bit)/CE5.0/XP Embedded |
| Linux | Linux 2.4.x / 2.6.x |
| Unix | SCO Unixware 7.1.3, SCO OpenServer 5.0.6/5.0.7/6.0 |
| DOS | DOS |
| Hardware | EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, RoHS |
| Software | Microsoft WHQL Window XP |
| Operating Temperature | 0 to 60 °C ( 32 to 140 °F ) |
| Operating Humidity | 5% to 95% RH |
| Storage Temperature | -20 to 85 °C ( -4 to 185 °F ) |
| PCB Dimension | 144 x 102 |
| Bracket | Standard 121 |
| Manual | 771-SERIAL002-001 |  |
| Datasheet | SER4066RM | |
| Driver | SUN1999Driver V8.1.5.0 (WHQL) | |
| Version | sun1999driver v8.1.5.0 (whql) - 20150520 | |
| Update | 2015-06-09 19:00:49 | |
| Size | 4.4MB | |
| OS | Windows XP 32/64 bit Windows Embedded Standard |
| Driver | SUNDOS1.00.00.003.zip | |
| Version | V1.00.00.006 | |
| Update | 2014-08-19 10:36:25 | |
| Size | 21KB | |
| OS | DOS |
| Driver | WinCE 6.0_Driver_V1.1.0.0.zip | Product Details
