2M USB 2.0 To Serial Adaptor FTDI Chipset supports Port retention
$57.50
Tax included
2M USB 2.0 To Serial Adaptor FTDI Chipset supports Port retention
Introduction
nThe USB to RS232 Serial Adapter with FTDI FT232RL chip is a reliable solution for connecting legacy serial devices to modern USB-enabled computers. Designed with the industry-leading FTDI chipset, it ensures exceptional compatibility, stable data transfer, and broad operating system support. With port retention functionality, the adapter maintains consistent COM port assignments across reboots or reconnections, making it ideal for applications that require stable communication channels. Compact and easy to use, this adapter is perfect for industrial automation, networking equipment, instrumentation, and other serial-based peripherals
nSpecifications
1. With FTDI FT232 Chipset.
2.Full compliance with the USB Specification v2.0 and back compatible v1.1;
3. Designed for ideal connections to Cellular Phone, Digital Camera, Modems or ISDN terminal adapters;
4. Support the RS232 Serial interface;
5. Support automatic handshake mode;
6. Over 1Mbps data transfer rate;
7. Support Remote wake-up and power management;
8. 96 bytes buffer each for upstream and downstream data flow;
9. Support default ROM or external EEPROM for device configuration;
10. Windows 98/98S/ME/2000/XP/Vista/7/8/10/11 and Mac OS/Linux2.4;
11. Cable length: 2M.
n1. With FTDI FT232 Chipset.
2.Full compliance with the USB Specification v2.0 and back compatible v1.1;
3. Designed for ideal connections to Cellular Phone, Digital Camera, Modems or ISDN terminal adapters;
4. Support the RS232 Serial interface;
5. Support automatic handshake mode;
6. Over 1Mbps data transfer rate;
7. Support Remote wake-up and power management;
8. 96 bytes buffer each for upstream and downstream data flow;
9. Support default ROM or external EEPROM for device configuration;
10. Windows 98/98S/ME/2000/XP/Vista/7/8/10/11 and Mac OS/Linux2.4;
11. Cable length: 2M.
n n n n n
n
FT232RL features:
nSingle chip USB to asynchronous serial data transfer interface.
nEntire USB protocol handled on the chip - No USB-specific firmware programming required.
nUART interface support for 7 or 8 data bits, 1 or 2 stop bits and odd / even / mark / space / no parity.
nFully assisted hardware or X-On / X-Off software handshaking.
nData transfer rates from 300 baud to 3 Megabaud (RS422 / RS485 and at TTL levels) and 300 baud to 1 Megabaud (RS232).
nIn-built support for event characters and line break condition.
nNew USB FTDIChip-ID? feature.
nNew configurable CBUS I/O pins.
nAuto transmit buffer control for RS485 applications.
nTransmit and receive LED drive signals.
nNew 48MHz, 24MHz,12MHz, and 6MHz clock output signal Options for driving external MCU or FPGA.
nFIFO receive and transmit buffers for high data throughput.
n256 Byte receive buffer and 128 Byte transmit buffer utilising buffer smoothing technology to allow for high data throughput.
nAdjustable receive buffer timeout.
nSynchronous and asynchronous bit bang mode interface options with RD# and WR# strobes.
nNew CBUS bit bang mode option.
nIntegrated 1024 bit internal EEPROM for I/O configuration and storing USB VID, PID, serial number and product description strings.
nDevice supplied preprogrammed with unique USB serial number.
nSupport for USB suspend / resume.
nSupport for bus powered, self powered, and high-power bus powered USB configurations.
nIntegrated 3.3V level converter for USB I/O .
nIntegrated level converter on UART and CBUS for interfacing to 5V - 1.8V Logic.
nTrue 5V / 3.3V / 2.8V / 1.8V CMOS drive output and TTL input.
nHigh I/O pin output drive option.
nIntegrated USB resistors.
nIntegrated power-on-reset circuit.
nFully integrated clock - no external crystal, oscillator, or resonator required.
nFully integrated AVCC supply filtering - No separate AVCC pin and no external R-C filter required.
nUART signal inversion option.
nUSB bulk transfer mode.
n3.3V to 5.25V Single Supply Operation.
nLow operating and USB suspend current.
nLow USB bandwidth consumption.
nUHCI / OHCI / EHCI host controller compatible.
nUSB 2.0 Full Speed compatible.
n-40°C to 85°C extended operating temperature range.
nFTDI drivers download link:
nhttp://www.ftdichip.com/Drivers/VCP.htm
nDriver installing guide:
nhttp://www.ftdichip.com/Support/Documents/InstallGuides.htm
nFT232RL chip datasheet:
nhttp://www.ftdichip.com/Support/Documents/DataSheets/ICs/DS_FT232R.pdf
n
CB-U2DB9-FTDI-2M
100 Items
