USB-C 7-in1 Mini Dock with 4K/30Hz HD, USB Hub, 100W PD, SD/microSD

Introduction

This is a multifunctional docking station designed for ordinary home users, students, and professionals seeking high cost-performance. Whether for home office use, online learning, or multimedia entertainment, this docking station provides stable connections and a variety of interface expansions to meet daily life and work requirements. It features a compact and durable Aluminium alloy casing, combining an elegant appearance with excellent durability. The docking station is equipped with a 4K/30Hz HDMI port. The built-in USB-C PD port supports up to 100W of fast charging. It also offers a range of USB ports, including a USB 2.0 Type-C Hub, a USB 3.0 Type-A port, and two USB 2.0 Type-A ports to meet various peripheral connectivity needs. Additionally, the docking station includes an SD card slot and a microSD card slot, supporting quick file reading and transfer; however, note that SD and microSD card slots cannot be used simultaneously to avoid read/write conflicts.

Features

■Reversable USB-C Interface w/ 7 functions

■4K/30Hz HDMI (DP-Alt Mode Only)

■1 x USB 3.0 Type A (5Gbps, USB 3.2 Gen 1)

■1 x USB 2.0 Type-A (480Mbps)

■1 x USB 2.0 Type-C (480Mbps)

■1 x SD 2.0 and microSD 2.0

■1 x PD 100w

System and Cable Requirements

The host computer requires DP-Alt Mode.

n
• This product must be directly connected to the Type-C port on the computer body and cannot be used through a USB hub or extended USB ports.
n
• This product supports USB PD (Power Delivery), but not all USB Type-C devices (PD compatible) will work properly.
n
• Although this product generally supports plug-and-play, occasional issues with USB recognition timing may prevent normal display or operation. Please try reconnecting; this is not a fault or issue with the product.
n
• This product must be used with Windows OS or Mac OS; it will not work (display) during startup or in the BIOS screen.
n
• Even with supported devices and connection environments, it may not function properly.
n
• When connecting 2.0/1.1 specification products, the maximum transfer speed will depend on the slower specification, so please note.
n
• This product does not guarantee connection and operation with all USB Type-C devices.
n
• This product supports USB 5Gbps specification, but the USB 5Gbps transfer speed is based on the specification value.
n
