CAT6A UTP Inline Joiner/Coupler

Introduction

This CAT6A UTP Coupler is a high-performance, inline RJ45 female-to-female adapter designed to join two unshielded Cat6A patch cables while maintaining full 10 Gigabit Ethernet performance. Compact and easy to use, it provides a reliable solution for extending cable runs, creating temporary connections, or adapting installations without sacrificing network speed or signal quality. Ideal for offices, data centres, and structured cabling environments where unshielded twisted pair (UTP) cabling is deployed.

Specifications

Standards & Performance

n
• Category: CAT6A (Unshielded)
n
• Supported applications: 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, 100BASE-TX
n
• Bandwidth: Up to 500 MHz
n
• Standards compliance: ANSI/TIA-568.2-D, ISO/IEC 11801, EN 50173
n
• Performance: Meets or exceeds Cat6A channel requirements when used with compliant cables
n

Mechanical

n
• Connector type: RJ45 8P8C female to RJ45 8P8C female (inline)
n
• Housing: Durable ABS/PC plastic body (non-shielded)
n
• Contact material: Phosphor bronze with 50 µin gold-plated contact area
n
• Mating cycles: ≥ 750 insertion/removal cycles
n
• Dimensions: Compact inline design (~30–40 mm length, model dependent)
n
• Weight: Lightweight, easy to install
n

Environmental

n
• Operating temperature: -20°C to +70°C
n
• Storage temperature: -40°C to +85°C
n
• Humidity: 10% – 90% non-condensing
n

Safety & Compliance

n
• Flammability rating: UL94V-0 (plastic parts)
n
• RoHS & REACH compliant, lead-free construction
n

Compatibility

n
• Suitable for Cat6A UTP patch cables
n
• Backward compatible with Cat6 and Cat5e UTP cables
n
• Designed for UTP systems where shielding is not required
n

Applications

n
• Cable extensions in office and data centre environments
n
• Quick fixes for cable length limitations
n
• Reliable, tool-free solution for structured cabling systems
