1.5M OM5 10/40/100 Gb 50/125 M/M Duplex Fibre Patch Cable

Introduction

OM5 is the designation given to a new type of fiber optic glass intended for use with Short Wave Division Multiplexing (SWDM).

OM5 is designed to support at least four low-cost wavelengths in the 850-950 nm range, enabling optimal support of emerging Shortwave Wavelength Division Multiplexing (SWDM) applications that reduce parallel fiber count by at least a factor of four to allow continued use of just two fibers (rather than eight) for transmitting 40 Gb/s and 100 Gb/s and reduced fiber counts for higher speeds.

OM5 cabling supports all legacy applications at least as well as OM4, and is fully compatible with OM3 and OM4 cabling.

The OM5 optical and mechanical attributes are compliant with OM4 50/125 μm specifications and include the additional specifications of effective modal bandwidth and attenuation at 953 nm. WB MMF is intended for operation using vertical-cavity-surface-emitting-laser (VCSEL) transceivers across the 846 to 953 nm wavelength range.

Specifications

Connectors: LC

Supported Speed:  10Gb/40G/100G

Jacket Materials: LSZH-FR ( Low Smoke Zero Halogen plus Fire Resistant )

Fibre Cable OD: 3mm

Colour: Green

Fibre Mode: Multimode 50/125

Fibre Type: Duplex
