CAT6A/CAT7 8P8C Fully Shielded Connector for 22-23 AWG Solid Core Cables ( 2 Piece ) for Cable with OD 7.2mm to 8.2mm
$3.20
Tax included
CAT6A/CAT7 8P8C Fully Shielded Connector for 22-23 AWG Solid Core Cables ( 2 Piece ) for Cable with OD 7.2mm to 8.2mm
Introduction
nThis Cobtel FTP CAT6A/CAT7 RJ45 Plug is with 4UP + 4DOWN TWO-PIECE with cable clamp. This modular connector comes with conductive load BAR. The 8-position, 8-wire, FTP modular plug with T-sleeve, preventing the shrapnel or latch from collusion with each other. It's suitable for solid or stranded twisted pair patch cable with conductor insulation diameter of Ø1.45±0.05mm and jacket diameter of OD7.2mm～OD8.2mm.
nn
Specifications
nn
| n General Specification n | n|
| n Brand Name: n | nn COBTEL n | n
| n Interface n | nn RJ45 n | n
| n Positions/Load Contacts n | nn 8P8C n | n
| n Cable Type n | nn Solid/Strand cable n | n
| n Color n | nn Clear n | n
| n Dimension n | n|
| n Compatible Cable Diameter n | nn OD7.2mm～OD8.2mm n | n
| n Conductor Insulation Diameter n | nn Ø1.45±0.05 n | n
| n Material Specification n | n|
| n Housing n | nn 94V-2 or 94V-0 n | n
| n Contacts n | nn 3prongs Brass or Phosphor copper n | n
| n Material Type n | nn Polycarbonate n | n
| n Gold plating n | nn Yes 50U n | n
| n Plug Shield Plating Material n | nn Nickel n | n
| n Environmental Specifications n | n|
| n Maximum Operating Temperature n | nn 85°C n | n
| n Minimum Operating Temperature n | nn -40°C n | n
| n Compliance/Certifications n | n|
| n RoHS n | nn Compliant n | n
| n REACH n | nn Compliant n | n
| n IEC n | nn Compliant n | n
| n CE n | nn Compliant n | n
| n ISO 9001:2015 n | nn Compliant n | n
| n UL n | nn Compliant n | n
CB-RJ45-72
100 Items
