CAT6 8P8C Connector for Solid / Stranded Cables ( 2 Piece )
$0.88
Tax included
CAT6 8P8C Connector for Solid / Stranded Cables ( 2 Piece )
Introduction
nCob CAT6 8P8C Connector for Solid /Stranded Cable ( 2 Piece ) with 2 layer structure ( 2UP+ 6DOWN ).
nSpecifications
n| n Part No. CB-RJ45-29 n | nn
| n
| n Performance Category n | nn Cat.6 n | n
| n Description n | nn 8P8C 2 Layers ( 2 Up and 6 Down ) n | n
| n Wire Insert Diameter n | nn 1.0mm n | n
| n Maximum Cable O.D. Size n | nn 6.2mm n | n
| n Maximum conductor W/insulation O.D. Size n | nn 1.0mm n | n
| n Rated Current n | nn 125V,AC. 1.5A @25℃ n | n
| n Conductor type n | nn 3 Prongs for Solid /Stranded Cables n | n
| n Insulation Resistance n | nn 500MΩ, Min. 100V DC /Min. n | n
| n Insertion Force & Withdrawal Force n | nn 30N Max. n | n
| n Durability n | nn 750 cycles min. n | n
| n Packaging Features n | nn 100 or 1000pcs/bag n | n
| n Plug Housing Material n | nn UL 94V2 rated clear Polycarbonate (PC) n | n
| n Contact Blades Material n | nn Gold Plated n | n
| n Operation Temperature n | nn - 40℃ ~ 85℃ n | n
| n Storage temperature n | nn - 40℃ ~ 70℃ n | n
| n Compliance n | nn UL 94V-2, ROHS and Reach n | n
CB-RJ45-29
100 Items
New
