EVA214 Extender Set = Transmitter EVA12L + Receiver EVA-02R
â—† Use the inexpensive CAT5/5e/6 UTP cable for extender connection
â—† Support audio function
â—† 1 local unit for distributing 1 port through CAT5 and 2 VGA ports for local display
â—† Support VGA, SVGA and Multisync monitors
â—† Gain (equalization) control selector designed for optimum signal clarity
â—† Support the resolution of 1600 x 1200 @ 60M and 1280 x 1024 @ 150 meters with the high quality CAT5 cable
â—† Support IR remote control users can achieve the remote job with the range of 5 meters
â—† Ideal for public broadcasting, exhibits, retail stores, courtrooms, stock tickers, bus station, etc.
â—† Optional VESA mounting bracket supported (for VESA mountable display attachment)
| EVA-02R | EVA-12L | EVA-124L ERVA-124L | EVA-128L ERVA-128L | ||
| Purpose (play as) | Remote unit | Local unit | |||
| Input Port | VGA | N/A | HDB15-M x 1 | ||
| Audio | N/A | 3.5mm Ear Jack x 1 | |||
| Extension | RJ-45 x 1 | N/A | |||
| Output Port | VGA | HDB15-F x 2 | HDB15-F x 2 | ||
| Audio | 3.5mm Ear Jack x 2 | 3.5mm Ear Jack x 2 | |||
| Extension | N/A | RJ-45 x 1 | RJ-45 x 4 | RJ-45 x 8 | |
| Remote Control Support | N/A | N/A | ERVA-124L | ERVA-128L | |
| Extension cable type | CAT5, CAT5e or CAT6 | ||||
| Max. distance | 150 meters | ||||
| Resolution | Max. 1600 x 1240 | ||||
| Equalizer selector | 4-position slide switch | N/A | N/A | N/A | |
| Status indicators | Power (Green) x 1, Active (Yellow) x 1 | ||||
| Operating voltage | 9V DC, 600mA | ||||
| Weight (g) | 190 | ||||
| H x W x D (mm) | 20 x 103 x 69 | 20 x 103 x 69 | 20 x 180 x 85 | 20 x 180 x 85 | |
