Wireless HDMI extender 100m Supports 1080P 60Hz

Introduction

This product will let the user experience of transmitting the HD content by wireless. The HDMI sources over wireless kit extends high-definition video and audio to any HDTV displays up to 100 meters away.

The extender follows the TCP / IP standard Wireless Transport Protocol, so it has high transmission rate and strong anti-interference capability. It also supports HDMI mirror output and infrared remote control extension. The HDMI Wireless Extender is widely applicable to office presentation, lecture, education, conference, family entertainments etc.

  Features


1. Contains a transmitter (TX) and a receiver (RX). The HDMI signal over wireless transmission from the transmitter to the receiver

2. The TX support one HDMI loop output, for local screen monitor

3. Support HDMI resolution: 480i/576i~1080P@50/60Hz and SVGA~WUXGA

4. Digital 2.4G & 5GHz dual frequency wireless A/V transmission, high transmission rate and strong anti-interference capability

5. Using an external dual - gain antennas. Full HD 1080p transmits up to 100 meters wirelessly in open space.( May be affected by the use environment)

6. Extends infrared remote to control source device from display side

7. Support OSD, for informed of device status

8. Simple Plug and Play. Full hardware design, no software installation required

9. Support Web Configuration Interface, Simple and easy to use

SPECIFICATIONS

HDMI Compliance…………………………………..………………………………….. HDCP1.4
HDMI resolution ……………up to 1080P@50/60Hz&SVGA/XGA/WXGA/SXGA/WXGA+/UXGA/ WSXGA+/ WUXGA
HDMI Audio Format……………………………………………………………………………….. LPCM2.0
HDMI Max bandwidth………………………………………………………….……………………...225MHz
HDMI Max baud rate…………………….………………….………………….……………………6.75Gbps
Input/Output TMDS signal ………….……………………………….……………….0.5~1.5Volts p-p(TTL)
Input/Output DDC signal ……………………………………………..……………………. 5Volts p-p (TTL)
HDMI output cable distance………………………………………...≤12m AWG26 HDMI standard cable
Antenna type…………………………………………………………..…. External dual 3dBi gain antenna
Wirelessstandard………………………………………………………………………...IEEE 802.11a/b/g/n
Wireless Band…………………………………………………………………….. 2.4GHz, 5GHz ISM Band
Max Data rates………………………………………………………………………… 2T2R up to 300Mbps
Transmit Output Power（IPEX）…………………………………………………….……….……16±2dBm
Transmission distance………………………………………………………….up to 100m (in open space)
IR Carrier frequency…………………………………………………………………………………….38KHz
TX/RX Max working current ……………………………………………………….……….…….………. 1A
Power adapter format Input ……......….….…….…….…….…. AC 100V～240V 50HZ/60Hz, DC5V/2A
Operating Temperature range ……..…………….……………………………………………. -5 to +45℃
Storage Temperature range……………………………………………………………………. -20 to +60℃
Operating Humidity range ………………………….….……….……….10 to 90%RH (No Condensation)
Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation)
Case Dimension (L x W x H) ………………………………….…………………….127.5x127.5x25 (mm)
Weight …….…………………………….………………………………………….………..TX175g/RX170g
